When you need a powerful large area rotary mower, the Jacobsen HR700 is the machine that will get the job done. With MARBAIN® Boron Alloy Steel Blades it can cut roughs, surrounds and other large areas effortlessly in all conditions. It boasts the widest width of cut and the narrowest transport width in class.

The Jacobsen HR700 has tilt sensor technology, which warns you of safe working angles when you’re mowing, combined with being a lower weight for efficiency and fuel economy, and unrivaled comfort during operation keeps you mowing until the work is done.

Key Features of the Jacobsen HR700 Powerful Large Area Rotary Mower

  • High strength, high performance steel throughout and compact chassis design
  • SureTrac™ 4WD Parallel-Cross-Series traction system
  • Wing decks fold up inside the front deck to easily gauge accessibility
  • Q Amp® variable rate steering system
  • Operator lift lower controls & onboard diagnostics
  • InCommand™ controlI system full colour display screen
  • Lightweight durable deck pan design made from high strength steel
  • Bolt together construction for easy deck maintenance and repairs
  • ISO mounted operator platform for comfortable, productive ride
  • Cooling Reversing Engine Fan
  • Maintenance free wet parking brakes

Brand: Jacobsen
 Decks and Cutting Units
 Number and Size  1 x 60” (1.52m) front deck; 2 x 60” (1.52m) wing units
 Blade Material  MARBAIN® boron alloy steel
 Deck Lift and Lower  Individual via fingertip operated joysticks
 Weight Transfer  On demand electrically operated hydraulic weight transfer system
 Deck Construction  11 gauge (3mm) Strenx, high strength steel shell


 Traction, Brakes and Speed
 Traction Drive  Hydrostatic closed loop parallel-cross-series SureTrac™ system
 Deck Drive Nine individual hydraulic motors with self lubricating integral bearings
 Hydraulic System 13.3 gal. (50.2L) reservoir with 10 micron remote charge filters and suction screening at tank. Oil cooler in side by side radiator.
 Service Brakes  Dynamic through hydrostatic traction system
 Parking Brakes  Automatic wet parking brakes integrated into wheel motors
 Steering  Power Steering
 Mower Speed 10mph (16.4km/h)
 Reverse Speed   4mph (6.4km/h)


 Weights and Dimensions
 Weight (excluding fuel) 4023lbs (1825kg), 4479lbs (2032kg) with cab
 Length (less catchers)  143” (3.62m) front deck down
 Overall Height (ROPS up)  83” (2.1m)
 Wheelbase  64” (1.65m)
 Transport Width   65” (1.67m)
 Working Width 176” (4.48m)


 Mower Warranty  2 Years
  • Road light kit
  • Canopy/sunshaden
  • Climate controlled cab
  • Cab accessories - road light kit, Rear wiper kit
